Netgear WNR612 [11/99] Connecting to the router

2. Getting Started with NETGEAR genie

Connecting to the router

This chapter explains how to use NETGEAR genie to set up your router after you complete

cabling as described in the installation guide and in the previous chapter.

This chapter contains the following sections:

• Router Setup Preparation

• Types of Logins and Access

• NETGEAR genie Setup

• Use NETGEAR genie After Installation

• Upgrade Router Firmware

• Router Dashboard (Basic Home Screen)

• Join Your Wireless Network

• NETGEAR genie App and Mobile genie App
