NETGEAR genie Advanced Home

N150 2-Port Wireless Router WNR612v3

You can specify the pool of IP addresses to be assigned by setting the starting IP address

and ending IP address. These addresses should be part of the same IP address subnet as

the router’s LAN IP address. Using the default addressing scheme, define a range between

192.168.1.2 and 192.168.1.254, although you might want to save part of the range for

devices with fixed addresses.

The router delivers the following parameters to any LAN device that requests DHCP:

• An IP address from the range you have defined

• Subnet mask

• Gateway IP address (the router’s LAN IP address)

• Primary DNS server (if you entered a primary DNS address in the Internet Setup screen;

otherwise, the router’s LAN IP address)

• Secondary DNS server (if you entered a secondary DNS address in the Internet Setup

screen)

To use another device on your network as the DHCP server, or to specify the network

settings of all of your computers, clear the Use Router as DHCP Server check box and click

Apply. Otherwise, leave this check box selected. If this service is not enabled and no other

DHCP server is available on your network, set your computer IP addresses manually so that

it can access the router.

Address Reservation

When you specify a reserved IP address for a computer on the LAN, that computer always

receives the same IP address each time it accesses the router’s DHCP server. Assign

reserved IP addresses to computers or servers that require permanent IP settings.

 To reserve an IP address:

1. In the Address Reservation section of the screen, click the Add button.

2. In the IP Address field, type the IP address to assign to the computer or server. (Choose an

IP address from the router’s LAN subnet, such as 192.168.1.x.)

3. Type the MAC address of the computer or server.

Tip: If the computer is already on your network, you can copy its MAC

address from the Attached Devices screen and paste it here.

4. Click Apply to enter the reserved address into the table.

The reserved address is not assigned until the next time the computer contacts the

router’s DHCP server. Reboot the computer, or access its IP configuration and force a

DHCP release and renew.

To edit or delete a reserved address entry, select the radio button next to the reserved

address you want to edit or delete. Then click Edit or Delete.
