![Netgear WNR612 [90/99] Technical specifications](/views2/1205513/page90/bg5a.png)
Supplemental Information
90
N150 2-Port Wireless Router WNR612v3
Technical Specifications
Wireless Wireless communication Enabled
SSID name See router label
Security WPA2-PSK (AES)
Broadcast SSID Enabled
Transmission speed Auto
*
Country/region United States in the US; otherwise varies by region
RF channel 6 until region selected
Operating mode Up to 150 Mbps
Firewall Inbound (communications coming
in from the Internet)
Disabled (bars all unsolicited requests)
Outbound (communications going
out to the Internet)
Enabled (all)
*. Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can .
Network conditions and environmental factors, including volume of network traffic, building materials and
construction, and network overhead, lower actual data throughput rate can vary.
Table 4. WNR612v3 Router specifications
Feature Description
Data and routing protocols TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Dynamic DNS, and UPnP.
Power adapter AC plug is
localized
• 110V-240V, 50/60 Hz, input
• All regions (output): 5V DC @ 1A, output
Dimensions 126 x 105 x 30mm (4.96 x 3.7 x 1.2 in)
Weight 0.123 kg (0.27 lb)
Operating temperature -5° to 45° C (23º to 113º F)
Operating humidity 95% maximum relative humidity, noncondensing
Electromagnetic Emissions China CCC & SRRC, CE
LAN 10BASE-T or 100BASE-Tx, RJ-45
WAN 10BASE-T or 100BASE-Tx, RJ-45
Wireless Maximum wireless signal rate complies with the IEEE 802.11 standard. See the
footnote for the previous table.
Table 3. Factory default settings (Continued)
Feature Default behavior
