Netgear WNR612 [50/99] Managing your network

6. Administration

Managing your network

This chapter describes the router settings for administering and maintaining your router and

home network. See

Remote Management on page 76 for information about checking the status

of your router over the Internet, and Traffic Meter on page 78 for information about monitoring

Internet traffic on your router’s Internet port.

This chapter includes the following sections:

• Upgrade the Firmware

• View Router Status

• View Logs of Web Access or Attempted Web Access

• Manage the Configuration File

• Set Password
