93
5. Using On-Screen Menu
HintsonHowtoSetUpLANConnection
TosetuptheprojectorforaLANconnection:
AccesstheHTTPserverfunctiontodisplaythewebbrowser(→page44)andselect[NETWORKSETTINGS]→
[SETTINGS]→[WIRELESSLAN]→[PROFILE1]or[PROFILE2].
TwosettingscanbesetfortheUSBWirelessLANUnit.
Nextselect[SETTINGS]foryourselectedprole,andset[ENABLE]or[DISABLE]for[DHCP],[IPADDRESS],
[SUBNETMASK],and[GATEWAY].Lastclick[SAVE].Toreectchanges,clickthe[SETTING]tabandthenclick
[APPLY].(→page47)
TorecallLANsettingsstoredintheprolenumber:
Use[PROFILE1]or[PROFILE2]setontheHTTPserver,fromtheprojector’menu,select[SETUP]→[WIRELESS
LAN]→[PROFILE]→[PROFILE1]or[PROFILE2].Lastselect[OK]andpresstheENTERbutton.(→page92)
To connect a DHCP server:
Fromtheprojectormenu,select[SETUP]→[WIREDLAN]→[SETTINGS]→[DHCP]→[ON]andpresstheENTER
button.TospecifyIPaddresswithoutusingtheDHCPserver,usetheHTTPserverfunction.(→page44)
TosetonlyforwirelessLAN(NETWORKTYPEandWEP/WPA):
AccesstheHTTPserverfunctiontodisplaythewebbrowser(→page44)andselect[NETWORKSETTINGS]→
[SETTINGS]→[WIRELESSLAN]→[PROFILE1]or[PROFILE2].
Makenecessarysettingsfor[SETTINGS]andclick[SAVE].
Fromtheprojectormenu,select[SETUP]→[WIRELESSLAN]→[PROFILE]→[PROFILE1]or[PROFILE2].
To select an SSID:
AccesstheHTTPserverfunctiontodisplaythewebbrowser(→page44)andselect[NETWORKSETTINGS]→
[SETTINGS]→[WIRELESSLAN]→[CONNECTION]→[SITESURVEY]andselecttheID.
Ifyoudonotuse[SITESURVEY],typetheSSIDin[CONNECTION]andselect[INFRASTRUCTURE]or[ADHOC].
(→page47)
Toreceivelampreplacementtimeorerrormessagesviae-mail:
AccesstheHTTPserverfunctiontodisplaythewebbrowser(→page44)andselect[NETWORKSETTINGS]→
[ALERTMAIL],andset[SENDER’SADDRESS],[SMTPSERVERNAME],and[RECIPIENT’SADDRESS].Last,
click[SAVE].(→page49)
Toexecute[EASYCONNECTION]usingImageExpressUtilityLite:
The[EASYCONNECTION]isamodethatcanabbreviatethetroublesomeLANsettingswhenusingtheImage
ExpressUtilityLiteandconnectingthePCandprojectorviaawirelessLAN.
TheImageExpressUtilityLiteiscontainedonthesuppliedNECProjectorCD-ROM.
Touse[EASYCONNECTION],accesstheHTTPserverfunctiontodisplaythewebbrowser(→page44)andselect
[NETWORKSETTINGS]→[SETTINGS]→[WIRELESSLAN]→[EASYCONNECTION].Nextselect[SETTINGS]
→[CHANNEL].Lastclick[SAVE].
Fromtheprojectormenu,select[SETUP]→[WIRELESSLAN]→[PROFILE]→[EASYCONNECTION].
NOTE:The[EASYCONNECTION]functionisavailableonWindows7,WindowsVistaorWindowsXPSP3.
