![Nec M420X [131/155] Maintenance](/views2/1205526/page131/bg83.png)
121
7. Maintenance
2. Removethelamphousing.
(1)Loosenthetwoscrewssecuringthelamphousinguntilthephillipsscrewdrivergoesintoafreewheelingcondi-
tion.
•Thetwoscrewsarenotremovable.
•Thereisaninterlockonthiscasetopreventtheriskofelectricalshock.Donotattempttocircumventthis
interlock.
(2)Removethelamphousingbyholdingit.
Interlock
To replace the lamp:
1. Removethelampcover.
(1)Loosenthelampcoverscrew
•Thelampcoverscrewisnotremovable.
(2)Pushandslidethelampcoveroff.
CAUTION:
Makesurethatthelamphousingiscool
enoughtobeforeremovingit.
[M420X/M420XV/M350XS/
M300XS/M260XS/M300WS/
M260WS]
