Nec M420X [123/155] Installation and connections
![Nec M420X [123/155] Installation and connections](/views2/1205526/page123/bg7b.png)
113
6. Installation and Connections
ExampleofwirelessLANconnection
(NetworkType→Infrastructure)
PC with wireless
LAN card inserted
PC with built-in wireless
LAN function
Wired LAN
Wireless access point
USB Wireless LAN Unit
Toenabledirectcommunication(i.e.,peer-to-peer)betweenpersonalcomputersandprojectors,youneedto
selecttheAdHocmode.
UsetheHTTPserverfunctiontomakethesettings.(→page44)
PC with wireless
LAN card inserted
PC with built-in wireless
LAN function
UsetheHTTPserverfunctiontomakethesettings.(→page44)
ExampleofwirelessLANconnection(NetworkType→AdHoc)
USB Wireless LAN Unit
