5. Using On-Screen Menu

Sampleimagewhentheappropriateaspectratioisautomaticallydetermined

M350X/M300X/M260X/M230X/M420X/M420XV/M350XS/M300XS/M260XS

[Computersignal]

Aspectratioofincomingsignal 4:3 5:4 16:9 15:9 16:10

Sampleimagewhentheappro-

priate aspectratioisautomati-

cally determined

[Videosignal]

Aspectratioofincomingsignal 4:3 Letterbox Squeeze

Sampleimage when theas-

pectratio isautomatically de-

termined

NOTE:Todisplayasqueezedsignalprop-

erly,select[16:9]or[WIDEZOOM].

M300W/M260W/M300WS/M260WS

[Computersignal]

Aspectratioofincomingsignal 4:3 5:4 16:9 15:9 16:10

Sampleimagewhentheappro-

priate aspectratio isautomati-

cally determined

[Videosignal]

Aspectratioofincomingsignal 4:3 Letterbox Squeeze

Sampleimage when theas-

pectratio isautomatically de-

termined

NOTE:Todisplayaletterboxsignalprop-

erly,select[LETTERBOX].

NOTE:Todisplayasqueezedsignalprop-

erly,select[16:9].

TIP:

• Imagepositioncanbeadjustedverticallyusing[POSITION]whenthe[16:9],[15:9],or[16:10]aspectratiosareselected.

• Theterm“letterbox”referstoamorelandscape-orientedimagewhencomparedtoa4:3image,whichisthestandardaspect

ratioforavidesource.

 Theletterboxsignalhasaspectratioswiththevistasize“1.85:1”orcinemascopesize“2.35:1”formovielm.

• Theterm“squeeze”referstothecompressedimageofwhichaspectratioisconvertedfrom16:9to4:3.

AdjustingtheVerticalPositionofImage[POSITION](notavailableonM300W/M260W/M300WS/

M260WS)

(onlywhen[16:9],[15:9],or[16:10]isselectedfor[ASPECTRATIO])

When[16:9],[15:9],or[16:10]isselectedin[ASPECTRATIO],theimageisdisplayedwithblackbordersonthetop

and bottom.

Youcanadjusttheverticalpositionfromthetoptothebottomoftheblackarea.
