138
8. Appendix
[M350XS/M300XS/M260XS/M300WS/M260WS]
398 (15.7)
140 (5.5)
75 (3)
11.5
(0.5)
175 (6.9)
24 (0.9)
39.8
(1.6)
130 (5.1)
150 (5.9)
29 (1.1)
200 (7.9)
134 (5.3)
288 (11.3)
21 (0.8)
309 (12.2)
Lens center
Lens center
Holes for ceiling mount
Unit:mm(inch)
