81
5. Using On-Screen Menu
Menu Descriptions & Functions [SETUP]
[GENERAL]
[M350X/M300X/M260X/M230X/M300W/M260W/
M420X/M420XV]
[M350XS/M300XS/M260XS/M300WS/M260WS]
UsingDigitalZoom[DIGITALZOOM](M350XS/M300XS/M260XS/M300WS/M260WS)
Thisfeatureallowsyoutoelectronicallyneadjusttheimagesizeonthescreen.Usethe◀ or ▶buttontolargeor
reducetheprojectedimage.
TIP:Toadjusttheprojectedimagesizeroughly,movetheprojectorawayorclosertothescreen.Toneadjustthezoom,usethe
[DIGITALZOOM]function.(→page21)
EnablingAutoKeystone[AUTOKEYSTONE]
Thisfeatureallowstheprojectortodetectitstiltandcorrectverticaldistortionautomatically.
ToturnontheAUTOKEYSTONEfeature,select[ON].ToadjusttheKEYSTONEfeaturemanually,select[OFF].
NOTE:The[AUTOKEYSTONE]functionisnotavailablewhenanorientationtypesuchas[CEILINGREAR],[DESKTOPREAR],
[CEILINGFRONT]otherthan[DESKTOP/FRONT]isselectedfor[ORIENTATION].
TIP:
• TherangeoftheAUTOKEYSTONEcorrectionvariesdependingonthemodelname.
M420X/M420XV/M350X/M300X/M260X/M230X/M300W/M260W:upto30degrees(vertical)
M350XS/M300XS/M260XS/M300WS/M260WS:upto20degrees(vertical)
• TheAUTOKEYSTONEcorrectionwilltakeeffectin2secondsafterchangingtheprojectionangleduringprojection.
CorrectingVerticalKeystoneDistortionManually[KEYSTONE]
Youcancorrectverticaldistortionmanually.(→page24)
TIP:Whenthisoptionishighlighted,pressingtheENTERbuttonwilldisplayitsslidebarforadjustment.
SavingVerticalKeystoneCorrection[KEYSTONESAVE]
Thisoptionenablesyoutosaveyourcurrentkeystonesettings.
OFF ������������������������ Does not save current keystone correction settings� It will return your keystone correction settings to
“zero”�
ON ������������������������� Saves current keystone correction settings
Savingyourchangeonceaffectsallsources.Thechangesaresavedwhentheprojectoristurnedoff.
NOTE:When[AUTOKEYSTONE]issetto[ON],[KEYSTONESAVE]isnotavailable.Nexttimeyouturnonthepower,theAUTO
KEYSTONEfunctionwillworkandthedatastoredwith[KEYSTONESAVE]willbeinvalid.
