100
6. Installation and Connections
[M350XS/M300XS/M260XS]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeisap-
proximately60"(1.52m)measureddiagonallywhentheprojectoris23inches(0.57m)fromthewallorscreen.The
largesttheimagecanbeis110"(2.8m)whentheprojectorisabout43inches(1.1m)fromthewallorscreen.
Distance
(Unit: m/inch)
Lens center
Screen Size
110"
100"
90"
84"
80"
1.10/43"
1.00/39"
0.89/35"
0.83/33"
0.78/31"
0.70/28"
0.57/23"
60"
72"
203.2(W)�152.4(H) / 80(W)�60(H)
223.5(W)�167.6(H) / 88(W)�66(H)
182.9(W)�137.2(H) / 72(W)�54(H)
170.7(W)�128.0(H) / 67(W)�50(H)
162.6(W)�121.9(H) / 64(W)�48(H)
146.3(W)�109.7(H) / 58(W)�43(H)
121.9(W)�91.4(H) / 48(W)�36(H)
Screen Size (Unit: cm/inch)
TIP:
• DigitalZoomcanresultinablurryimageduetotheelectroniczoom.
• Formoredetailsonthrowdistance,seepage102.
[M300WS/M260WS]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeis
approximately56"(1.4m)measureddiagonallywhentheprojectoris22inches(0.57m)fromthewallorscreen.The
largesttheimagecanbeis104"(2.6m)whentheprojectorisabout43inches(1.1m)fromthewallorscreen.
Distance
(Unit: m/inch)
Lens center
Screen Size
104"
100"
90"
80"
70"
1.10/43"
1.06/42"
0.95/37"
0.84/33"
0.72/28"
0.61/24"
0.57/22"
56.2"
60"
215.4(W)�134.6(H) / 85(W)�53(H)
224.0(W)�140.0(H) / 88(W)�55(H)
193.9(W)�121.2(H) / 76(W)�48(H)
172.3(W)�107.7(H) / 68(W)�42(H)
150.8(W)�94.2(H) / 59(W)�37(H)
129.2(W)�80.8(H) / 51(W)�32(H)
121.1(W)�75.7(H) / 48(W)�30(H)
Screen Size (Unit: cm/inch)
TIP:
• DigitalZoomcanresultinablurryimageduetotheelectroniczoom.
• Formoredetailsonthrowdistance,seepage102.
