CE790 User Manual

Features

 Remotely access computers on your KVM installation via the intranet

 Dual console operation – control your system from both the transmitter

and receiver USB keyboard, monitor, and mouse consoles

 OSD (On Screen Display) on both the transmitter and receiver units

 Supports GUI operation

 USB Keyboard and USB Mouse Ports

 RS-232 serial ports

– allows you to connect to a serial terminal for

configuration, and serial devices such as touchscreens and barcode

scanners

 Audio enabled (stereo speakers and microphone)

 USB overcurrent detection and prevention

 High resolution video – up to 1920 x 1080

 Supports widescreen formats

 Ultra-high quality video mode

 Hot pluggable

 Rack mountable

 Firmware upgradable – via web browser

 Auto MDIX – automatically detects cable type

 Supports Wide Screen formats

 *The EDID data for a widescreen is sent from the local video output port.

For widescreen modes and displays connect the monitor to the local video

output port or use an ATEN EDID emulator.

Note: 1. The CE790 AP and GUI operation instructions can be downloaded

from the ATEN website (www.aten.com).

2. RS-232 serial ports support Tx and Rx signals only.

3. The EDID data for a widescreen is sent from the local video output

port. For widescreen modes and displays connect the monitor to the

local video output port or use an ATEN EDID emulator.
