Chapter 1. Introduction

Requirements

Consoles

 A VGA, SVGA, SXGA, UXGA, or multisync monitor capable of the

highest resolution that you will be using on any computer in the

installation

Note: If you connect a DDC type monitor to the Transmitter Unit, the

monitor that connects to the Receiver Unit must be able to support

the highest video resolution that the DDC monitor can provide

 A USB keyboard

Note: You can use different brands and models of USB keyboard on the

Transmitter and Receiver Units, but support for multi-function

keyboards is limited to the standard 104 keys.

 A USB mouse

Note: You can use different brands and models of mouse on the

Transmitter and Receiver Units, but only the left and right mouse

buttons and scroll wheel features are supported. Other mouse

features are not supported.

Computers

The following equipment must be installed on each computer that is to be

connected to the system:

 A VGA, SVGA, SXGA, UXGA, or multisync card.

 USB host controller and Type A USB port.

Cables

 For optimal signal integrity, and to simplify the layout, we strongly

recommend that you use the high quality custom USB KVM Cable that is

provided with this package.
