Appendix
35
Specifications
Function CE790T CE790R
Connectors Console
Ports
Keyboard 1 x USB Type A Female (White)
Video 1 x HDB-15 Female (Blue)
Mouse 1 x USB Type A Female (White)
Speaker 1 x Mini Stereo Jack Female (Green)
Mic. 1 x Mini Stereo Jack Female (Pink)
RS-232 1 x DB-9 Female
(Black)
1 x DB-9 Male (Black)
KVM
Ports
KB / Video /
Mouse
1 x SPHD-17 Female
(Yellow)
N/A
Speaker 1 x Mini Stereo Jack
(Green)
Mic. 1 x Mini Stereo Jack
(Pink)
Power 1 x DC Jack (Black)
LAN 1 x RJ-45 Female (Black)
Pushbuttons OSD 1 x Pushbutton
Select 1 x Pushbutton
LEDs Status 1 (Green / Orange)
Power 1 (Green / Red)
Emulation Keyboard / Mouse USB
Power Consumption DC 5.3V, 6.62W DC 5.3V, 6.36W
Video Up to 1920 x 1080
Environment Operating Temp. 0–50ºC
Storage Temp -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.504 kg 0.482 kg
Dimensions
(L x W x H)
20.0 x 8.0 x 2.5 cm
