CE790 User Manual
4
Video Resolutions
Supported video resolutions are show in the table, below:
Resolution @ Hz Standard
640 x 480p 60 IBM VGA
72, 75 VESA
800 x 600p 56, 60, 72, 75
1024 x 768p 60, 70, 75 VESA
1152 x 864p 75 Apple Mac II
1280 x 768p, 960p, 1024p 60 VESA STD
1280 x 1024 75
1360 x 768 60
1152 x 864p 75
1440 x 900p 60
1680 x 1050p
1920 x 1080p
