ECS Elitegroup 755FX-A939 [11/83] Introducing the motherboard
![ECS Elitegroup 755FX-A939 [11/83] Introducing the motherboard](/views2/1212427/page11/bgb.png)
5
Introducing the Motherboard
Table of Motherboard Components
6 IDE2 Secondary IDE connector
12 JP1 Clear CMOS jumper
11 PANEL1 Front Panel switch/LED header
7 ATX1 Standard 20-pin ATX power connector
LABEL COMPONENT
5 IDE1 Primary IDE connector
8 SATA1~SATA2 Serial ATA connectors
13 FDD1 Floppy disk drive connector
2 ATX12V 4-pin +12V power connector
1 DIMM1~2 184-pin DDR SDRAM slots
14 USB3 ~ 4 Front Panel USB headers
3 CPU Socket Socket 939 for AMD K8 processor
4 CPUFAN1 CPU cooling fan connector
9 SJ1 Single-colored LED header
10 SPK1 Speaker header
This concludes Chapter 1. The next chapter explains how to install the motherboard.
* optional component
19 AGP1 Accelerated Graphics Port Slot
17 AUDIO1 Front panel audio header
16 CASFAN1 Case cooling fan connector
15 PCI1~5 32-bit add-on card slots
20 SPDIFO1 SPDIF out header
18 AUXIN1 Auxiliary in connector
21 CDIN1 Analog Audio Input connector
