Multi-Language Translation
Português
Opções de expansão
A placa principal vem equipada com as seguintes opções de expansão:
• Cinco ranhuras compatíveis com PCI v2.3 de 32 bits
• Uma ranhura AGP
• Dois colectores IDE que suportam quatro dispositivos IDE
• Uma interface da unidade de disquete
• Dois conectores SATA de 7 pinos
Esta motherboard suporta mastering bus Ultra DMA com taxas de transferência de
133/100/66MB/s.
LAN integrada (Opcional)
A LAN incorporada oferece as seguintes características:
• Suporta um funcionamento de 10/100 Mbps
• Suporta o funcionamento meio/completo duplex
• Suporta auto-negociação IEEE 802.3u cláusula 28
E/S integradas
A placa principal conta com um conjunto completo de portas e conectores E/S:
• Duas portas PS/2 para o rato e o teclado
• Uma porta de série
• Uma porta paralela
• Quatro portas USB
• Uma porta LAN (opcional)
• Tomadas de áudio para microfone, linha de entrada e linha de saída
Firmware do BIOS
A placa principal usa o AMI BIOS que permite aos usuários configurar vários recusos do
sistema, como:
• Gerenciamento de energia
• Alarmes de reativação
• Parâmetros da CPU
• Sincronização da CPU e memória
O firmware também pode ser usado para definir os parâmetros de diferentes velocidades de
clock do processador.
Alguns itens de software e especificação de hardware estão sujeitos a alterações
sem prévio aviso.
