Multi-Language Translation
Česky
Základní deska je dodávána s následujícími možnostmi rozšíření
• Pět 32bitové patice PCI v2.3
• Jedna patice AGP
• Dva konektory IDE, podporující připojení až 4 zařízení IDE
• Jedno rozraní pro disketovou mechaniku
• Dva 7kolíkové konektor SATA
Možnosti rozšíření
Vestavění síťové rozhraní LAN (volitelně)
Vestavěné síťové rozhraní LAN nabízí následující možnosti:
Integrovaný vstup/výstup
Základní deska je vybavena kompletní sadou vstupních portů a konektorů I/O:
• Dva porty PS/2 pro myš a klávesnici
• Jeden sériový port
• Jeden paralelní port
• Čtyři porty USB
• Jeden port LAN (volitelně)
• Zvukové konektory pro mikrofon, zvukový vstup a výstup
Firmware BIOS
Základní deska využívá BIOS formy AMI, který uživateli umožňuje nakonfigurovat mnoho
systémových parametrů, včetně následujících:
• Řízení spotřeby
• Alarmy při spouštění systému
• Parametry CPU
• Časování CPU a paměti
Firmware může být rovněž použit k nastavení parametrů pro různé taktovací frekvence
procesoru.
Některé technické parametry hardware a software se mohou měnit bez
předchozího upozornění.
Základní deska podporuje řízení sběrnice Ultra DMA s přenosovými rychlostmi 133/100/66
MB/s.
• Podpora 10/100Mbps přepínání
• Možnost polovičního a plného duplexu
• Podpora IEEE 802.3u klauzule 28 auto negotiation
