Using BIOS
PCI / Plug and Play Setup Page
.
This page sets up some parameters for devices installed on the PCI bus and those utilizing
the system plug and play capability.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
PCI / Plug and Play Setup
Help Item
Primary Graphics Adapter AGP
Allocate IRQ to PCI VGA Yes
PCI IDE BusMaster Enabled
Select which graphics controller
to use as the primary boot
device.
Primary Graphics Adapter (AGP)
This item indicates if the primary graphics adapter uses the PCI or the AGP bus. The default
AGP setting still lets the onboard display work and allows the use of a second display card
installed in an AGP slot.
Allocate IRQ to PCI VGA (Yes)
If this item is enabled, an IRQ will be assigned to the PCI VGA graphics system. You set this
value to No to free up an IRQ.
PCI IDE BusMaster (Enabled)
This item enables or disables the DMA under DOS mode. We recommend you to leave this
item at the default value.
Press <Esc> to return to the main menu setting page.
Supervisor Password
This item indicates whether a supervisor password has been set. If the password has been
installed, Installed displays. If not, Not Installed displays.
BIOS Security Features Setup Page
This page helps you install or change a password.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
BIOS Security Features Setup
Security Settings
Supervisor Password : Not Installed
Change Supervisor Password Press Enter
Help Item
Install or Change the
password.
