Multi-Language Translation
Español
Opciones de expansión
LAN en abordo (Optativo)
I/O integrado
La placa base tiene un conjunto completo de puertos I/O y conectores:
• Dos puertos PS/2 para ratón y de teclado
• Un puerto serie
• Un puerto paralelo
• Cuatro puertos USB
• Un puerto LAN (optativo)
• Clavijas de audio para micrófono, entrada de línea y salida de línea
Firmware de BIOS
La placa base utiliza AMI BIOS que permite a los usuarios configurar muchas funciones del
sistema, incluyendo las siguientes:
• Administración de energía
• Alarmas de encendido
• Parámetros CPU
• Temporización de memoria y CPU
El firmware también puede utilizarse para ajustar los parámetros para diversas velocidades del
reloj del procesador.
Algunas especificaciones de hardware y elementos de software están sujetos a
cambios sin previo aviso.
La placa principla viene con las sigtes. opciones de expansión:
• Cinco ranuras conforme con 32-bit PCI v2.3
• Una ranura AGP
• Dos cabezales IDE que soporta cuatro dispositivos IDE
• Una interfaz de lector de floppy
• Dos conectores 7-pin SATA
La placa principal soporta mastering de bus Ultra DMA con índices de transferencia de
133/100/66 MB/s.
El LAN abordo provee las sigtes. características:
• Soporta la operación 10/100 Mbps
• Dúplex completo y medio
• Soporta la autonegociación IEEE 802.3u claúsula 28
