Multi-Language Translation
Български
Дънната платка поддържа шина Ultra DMA 133/100/66MB/s.
Дънната платка има следните разширителни възможности:
• Пet слота 32-bit PCI v2.3
• един AGP слот
• Два колектора IDE с поддръжка на четири IDE устройства
• един конектор за флопидисково устройство
• два 7-щифтови SATA конектораs
Възможности за разширяване
Интегриран мрежов контролер (опция)
Спецификация на интегрирания мрежов контролер:
Интегриран Вход/Изход контролер
Дънната платка има пълен набор от I/O портове и конектори:
• два PS/2 порта за мишка и клавиатура
• един сериен порт
• един паралелен порт
• четири USB порта
• един LAN порт (опция)
• Аудио жакове за микрофон, линеен вход и линеен изход
BIOS Firmware
Дънната платка използва AMI BIOS с възможност за различни системни настройки,
включително
• управление на захранването
• Wake-up аларми
• параметри на процесора
• синхронизиране на процесора и паметта
настройка на скоростта на часовника на процесора
Хардуерните и софтуерни спецификации и параметри могат да бъдат
изменени без предупреждение.
• поддържа работа с 10/100 Mbps
• Half/Full duplex
• поддържа IEEE 802.3u клауза 28 за автоматичен диалог
