29
Using BIOS
Audio Device (Enabled)
This item enables or disables the AC’97 audio chip.
Ethernet Device (Enabled)
This item enables or disables the onboard Ethernet LAN.
Onboard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network add-in
card with a remote boot ROM installed.
OnBoard USB Function (Enabled)
Enable this item if you plan to use the USB ports on this motherboard.
USB Function For DOS (Disabled)
Enable this item if you plan to use the USB ports on this motherboard in a DOS environ-
ment.
Power Management Setup Page
This page sets up some parameters for system power management operation.
ACPI Aware O/S (Yes)
This itme supports ACPI (Advanced Configuraion and Power Management Interface). Use
this item to enable or disable the ACPI feature.
ACPI Enhanced Efficiency (Disabled)
This item allows you to enable or disable ACPI Enhanced Efficiency function.
Power Management (Enabled)
Use this item to enable or disable a power management scheme. If you enable power
management, you can use this item below to set the power management operation. Both
APM and ACPI are supported.
Suspend Time Out (Disabled)
This item sets up the timeout for Suspend mode in minutes. If the time selected passes
without any system activity, the computer will enter power-saving Suspend mode.
Resume on RTC Alarm (Disabled)
The system can be turned off with a software command. If you enable this item, the
systemcan automatically resume at a fixed time based on the system’s RTC (realtime clock).
Use the items below this one to set the date and time of the wake-up alarm. You must use an
ATXpower supply in order to use this feature.
Press <Esc> to return to the main menu setting page.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
Power Management Setup
ACPI Aware O/S Yes
ACPI Enhaned Efficiency Disabled
Power Management Enabled
Suspend Time Out Disabled
Resume on RTC Alarm Disabled
LAN/Ring Power On Disabled
Help Item
Yes / No
ACPI support for Operating
System.
Yes: If OS supports ACPI.
No: If OS does not support
ACPI.
