16
Installing the Motherboard
Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive
This section describes how to install IDE devices such as a hard disk drive and a CD-ROM
drive.
About IDE Devices
Your motherboard has a primary and secondary IDE channel interface (IDE1 and IDE2).
An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.
Table B: DDR (memory module) QVL (Qualified Vendor List)
The following DDR400 memory modules have been tested and qualified for use with this
motherboard.
Size Vendor Model Name
SAMSUNG K4H560838D-TCC4
TwinMOS TMD7608F8E50D
KingMax KDL388P4EA-50A
Winbond W942508BH-5
A-DATA ADD8608A8A-5B
A-DATA ADD8608A8A-4.5B
Kingston D3208DL2T-5 0323PT01
Kingston 9905192-012.A01
Hynix HY5DU5656822BT-D43
Hynix HY5DU56822BT-D43
GEIL
GE08L3264D1WL5NKT3H71
GEIL G208L364D1TG5NKT3C
Apacer AM3A568ACT-5A
256MB
Ramaxel MT-46V32M8 TG-5BC
SAMSUNG K4H560838D-TCC4
SAMSUNG K4H560838E-TCCC
Infineon HYB25D256800BT-5
Elixir N2DS25680BT-5T
Kingston D3208DL1T-5
PSC A2S56D30BTP
Transcend V58C2256804SAT5B
ValueSelect VS32MB-5 2B0402
CORSAIR CMX512-3200C2PT
CORSAIR CMX512-3500C2PT
Mushkin PC3500 level ONE
UNIFOSA USI 64M8B8-WB200-0431
GEIL
GE1GB3200BDC
AENEON
AED93T500
512MB
AENEON
AED83T500
1GB
CORSAIR CMX1024-3200PT
You must orient the cable connector so that the pin1 (color) edge of the
cable correspoinds to the pin 1 of the I/O port connector.
