24
Using BIOS
Press DEL to enter SETUP
Press the delete key to access the BIOS Setup Utility:
CMOS Setup Utility -- Copyright (C) 1985-2003, American Megatrends, Inc.
Advanced Setup
Power Management Setup
Features Setup
Standard CMOS Setup
BIOS Security Features
Standard CMOS setup for changing time, date, hard disk type, etc.
v02.54 (C)Copyright 1985-2003 American Mega trends, Inc.
PCI/Plug and Play Setup
Hardware Monitor
KEY FUNCTION
ESC Exits the current menu
Scrolls through the items on a menu
+/- Modifies the selected field’s values
F10 Saves the current configuration and exits setup
F1 Displays a screen that describes all key functions
F9 Loads an optimized setting for better performance
BIOS Navigation Keys
The BIOS navigation keys are listed below:
F8 Loads failsafe defaults
ESC Exits the current menu
CPU PnP Setup
: Move
F1: General Help
ESC: Exit
F10: SaveEnter : Select
F9: Optimized Defaults
+/-/: Value
Save Changes and Exit
Discard Changes and Exit
Load Optimal Defaults
