Multi-Language Translation
Deutsch
Erweiterungsmöglichkeiten
Onboard LAN (Optional)
Integrierte I/O
Das Motherboard hat einen vollständigen Satz von I/O-Schnittstellen bzw. -Anschlüssen:
• Zwei PS/2-Anschlüsse für Maus und Tastatur
• Eine serielle Schnittstelle
• Eine parallele Schnittstelle
• Vier USB-Anschlusse
• Ein LAN-Anschluss (optional)
• Audiobuchse für Mikrofon, Line-In und Line-Out
BIOS-Firmware
Das Motherboard verwendet AMI BIOS, das es Benutzern gestattet, viele Systemfunktionen
inkl. der Folgenden zu konfigurieren:
• Energieverwaltung
• Aufweckfunktionen
• CPU-Parameter
• CPU- und Arbeitsspeicherfrequenz
Die Firmware kann auch zur Einstellung von Parametern für verschiedene Prozessortaktge
-
schwindigkeiten verwendet werden.
Manche Hardwarespezifikationen und Softwareelemente können ohne Ankün
-
digung geändert werden.
Das motherboard bietet die folgenden Erweiterungsoptionen:
• F
ünf 32-bit PCIv2.3-Steckplätze
• Ein AGP-Steckplatz
• Zwei IDE-Header, die vier IDE-Geräte unterstützen
• Eine Schnittstelle für ein Floppydiskettenlaufwerk
• Zwei 7-Pin SATA Anschlüsse
Das Motherboard unterstützt UltraDMA Bus Mastering mit einer Übertragungsrate
von133/100/66 MB/Sek.
Das Onboard-LAN hat folgende Funktionen:
• Unterstützt Betrieb bei 10/100 Mbps
• Unterstützt half/full duplex Betrieb
• Unterstützt IEEE 802.3u Paragraph 28 Auto-Negotiation
