9
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled.
Jumper Settings
Jumper
Type
Description
Setting (default)
JP1
3-pin CLEAR CMOS 1-2: NORMAL
2-3: CLEAR
Before clearing the CMOS,
make sure to turn the system
off.
1
JP1
