Multi-Language Translation
日本語
拡張オプション
このメインボードには次の拡張オプションがあります:
• 32ビットPCIスロットが5つ
• AGPスロットが1つ
• IDEヘッダーが2つ (4つのIDEデバイスの接続を可能)
• フロッピーディスクインターフェースが1つ
• 7ピンSATAコネクタが2つ
このマザーボードは、133/100/66MB/秒の転送速度でのUltra DMAバスマスタリングを
サポートします。
オンボードLAN (オプション)
オンボードLANは、次の機能を提供します
• 10/100 Mbps動作対応
• 半/全二重動作
• IEEE 802.3u clause 28による自動折衝をサポート
統合I/O
マザーボードには、次のI/Oポートやコネクタを揃えています
• マウスとキーボード用のPS/2ポートが2つ
• シリアルポート が1つ
• パラレルポート が1つ
• USBポート が4つ
• LANポート が1つ(オプション)
• マイク、ラインイン、ラインアウト用オーディオジャック
BIOSファームウェア
本マザーボードはAMI BIOSを採用することにより、次の機能を含めた多様なシステム構
成を可能にしました
• 電源管理
• ウェークアップアラーム
• CPUパラメータ
• CPUおよびメモリのタイミング
さらに、所定のパラメータを設定することによって、プロセッサのクロック速度を変更す
ることもできます。
一部のハードウェア仕様とソフトウェアアイテムは、予告なしに変更すること
がありますので、ご了承ください。
