xiii
Package contents
Check your motherboard package for the following items.
Motherboard ROG STRIX Z370-E GAMING
Cables
4 x SATA 6Gb/s cables
1 x SLI HB BRIDGE (2-WAY-M)
1 x RGB LED extension cable
1 x Addressable LED extension cable
1 x Thermal sensor cable
Accessories
1 x I/O shield
1 x ASUS 2T2R dual band Wi-Fi moving antennas
(Wi-Fi 802.11a/b/g/n/ac compliant)
1 x CPU Installation tool
1 x ROG cable label
1 x ROG fan label
1 x 3D Printing Mount
1 x M.2 screw package
1 x CPU Fan holder
1 x Pack of cable ties
1 x ROG STRIX Door hanger
Application drive ROG motherboard support DVD
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.
