2-2
Chapter 2: Basic Installation
Chapter 2
3. Place nine (9) screws into the holes indicated by circles to secure the motherboard to
the chassis.
DO NOT overtighten the screws! Doing so can damage the motherboard.
®
STRIX Z370-E GAMING
