ASUS ROG STRIX Z370-E GAMING
1-5
Chapter 1
Recommended memory congurations
1.1.4 System memory
ThemotherboardcomeswithfourDDR4(DoubleDataRate4)QuadInlineMemoryModules
(DIMM)slots.
ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT
installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
®
STRIX Z370-E GAMING
ROG STRIX Z370-E GAMING
288-pin DDR4 DIMM sockets
DIMM_B1
DIMM_B2
DIMM_A1
DIMM_A2
