Asus ROG STRIX Z370-E GAMING [46/104] Front i o connector
![Asus ROG STRIX Z370-E GAMING [46/104] Front i o connector](/views2/1307907/page46/bg2e.png)
2-10
Chapter 2: Basic Installation
Chapter 2
2.1.7 Front I/O connector
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.1 Gen1
USB 3.1 Gen2
To install USB 3.1 Gen1 connector
To install USB 3.1 Gen2 connector
To install front panel connector
Thisconnectorwillonlytinone
orientation. Push the connector until it
clicks into place.
