ASUS ROG STRIX Z370-E GAMING
1-21
Chapter 1
14. Addressable RGB header (4-1 pin ADD_HEADER)
ThisconnectorisforindividuallyaddressableRGBWS2812BLEDstripswith
embeddedWS2811LEDdriverICs.
ROG STRIX Z370-E GAMING EXTREME ADD header
®
STRIX Z370-E GAMING
TheaddressableRGBheadersupportsWS2812BaddressableRGBLEDstrips(5V/Data/
Ground),withamaximumpowerratingof3A(5V)andamaximumof60LEDs.
Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyisswitched
offorthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere
damagetothemotherboard,peripherals,orcomponents.
• ActuallightingandcolorwillvarywithLEDstrip.
• IfyourLEDstripdoesnotlightup,checkiftheaddressableRGBLEDstripis
connectedinthecorrectorientation,andthe5Vconnectorisalignedwiththe5V
headeronthemotherboard.
• TheaddressableRGBLEDstripwillonlylightupundertheoperatingsystem.
• TheaddressableRGBLEDstripispurchasedseparately.
