ASUS ROG STRIX Z370-E GAMING
1-7
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIE_x1_1slot
2 PCIE_x16/x8_1slot
3 PCIE_x1_2slot
4 PCIE_x1_3slot
5 PCIE_x8_2slot
6 PCIE_x1_4slot
7 PCIE_x4slot
®
STRIX Z370-E GAMING
PCIE_X1_1
PCIE_X1_2
PCIE_X1_3
PCIE_X1_4
PCIE_X16/X8_1
PCIE_X8_2
PCIE_X4
