Chapter 1: Product Introduction
Chapter 1
13. RGB headers (4-pin RGB_HEADER1-2)
TheseconnectorsareforRGBLEDstrips.
TheRGBheadersupports5050RGBmulti-colorLEDstrips(12V/G/R/B),withamaximum
powerratingof2A(12V),andnolongerthan2m.
Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyisswitched
offorthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere
damagetothemotherboard,peripherals,orcomponents.
• ActuallightingandcolorwillvarywithLEDstrip.
• IfyourLEDstripdoesnotlightup,checkiftheRGBLEDextensioncableandthe
RGBLEDstripisconnectedinthecorrectorientation,andthe12Vconnectoris
alignedwiththe12Vheaderonthemotherboard.
• TheLEDstripwillonlylightupwhenthesystemisoperating.
• TheLEDstripsarepurchasedseparately.
PIN 1
+12V G R B
RGB_HEADER1
ROG STRIX Z370-E GAMING RGB_HEADER connectors
PIN 1
+12V G R B
RGB_HEADER2
®
STRIX Z370-E GAMING
A
A
B
B
