Quick Selection - Air flow/External Static Pressure

External static pressure (Pa)

Air flow (m

/h) 500 600 700 900 1100 1300 1500 1700

1.39

LS 234 165 56 - - - - - -

MS - - - 283 238 172 - - -

HS - - - - - 270 240 200 -

Air flow (m

/h) 700 1000 1300 1600 1900 2200 2500 2800 3100

2.69

LS - 203 168 114 30 - - - -

MS - - 260 234 196 138 55 - -

HS - - - - - 240 205 162 100

Air flow (m

/h) 1600 2000 2400 2800 3200 3600 4000 4400 4800

3.99

LS - 279 240 189 108 - - - -

MS - - 276 237 186 116 12 - -

HS - - - 271 238 198 148 79 -

External static pressure (Pa)

Air flow (m

/h) 500 600 700 900 1100 1300 1500 1700

1.39

LS 226 156 46 - - - - - -

MS - - - 271 222 150 - - -

HS - - - - - 248 213 166 -

Air flow (m

/h) 700 1000 1300 1600 1900 2200 2500 2800 3100

2.69

LS - 195 158 100 12 - - - -

MS - - 250 220 178 115 27 - -

HS - - - - - 217 177 126 58

Air flow (m

/h) 1600 2000 2400 2800 3200 3600 4000 4400 4800

3.99

LS - 267 224 171 82 - - - -

MS - - 260 219 160 84 - - -

HS - - - 253 212 166 110 33 -

Fan section incl. G2 filter

Fan section incl. G2 filter and heating coil

For other arrangements determine the fan speed and the characteristics from charts of component air pressure drops and fan curves (pages

12 and 13).
