Page 19
Water Connections (in mm)
280F
280
E
C' + 370
D' + 370
A' + 370
B' + 370
K
Ø16
25
C
A
B
D
280
280
E
F
280F
280
E
I' + 370
J' + 370
G' + 370
H' + 370
280E
280
F
I
J
G
H
Drain tube location
F
325
G' + 370
I' + 370
26
50
Ø16
Q
M
L
R
S
T
U
V
F
325
30
82
Ø16
F
325
I
G
N
O
P
M
L
Q
Drain tube location
Left hand connections
Right hand connections
- Connection type of heating and cooling coils : Ø 26/34 mm Male threaded (header extension is 37 mm).
- Connection type of cooling coil drain pan : copper tube Ø16 mm (tube extension is 20 mm).
- For an optimal efficiency, coils are to be connected per counter flow configuration.
All units are shown with left hand connections.
Horizontal units
Vertical units
Hand services A A' B B' C C' D D' E F G G' H H' I
Left 133 503 336 706 67 437 298 668 55 45 105 475 228 598 67
Right 67 437 298 668 133 503 336 706 35 45 67 437 162 532 105
Hand services I' J J' K L M N O P Q R S T U V
Left 437 162 532 73 195 111 249 299 574 85 52 102 377 552 590
Right 475 228 598 7 252 55 249 331 541 85 52 134 344 590 552
