Airwell Wespak 2.69 [23/28] Dimensions of options and accessory continued
![Airwell Wespak 2.69 [23/28] Dimensions of options and accessory continued](/views2/1408181/page23/bg17.png)
Page 23
370
C
B
55
180
100
324
185
Antifreeze damper "AG"
Dimensions of Options and Accessory (continued)
Superposed 3-way mixing box "MD3"
37030
164
32050 25
370
32025
740
A
B
90
164370
90
50
Dimensions in mm.
Sizes 1.39 2.69 3.99
A 582 970 1320
B 762 1150 1500
C 586 974 1324
Antifreeze damper and mixing box are supplied with ball joint assembly suitable for
Ø 6 mm linking rod.
