Page 9
Options and Accessories
6-row water
cooling coil
BF6
Direct expansion coil
BD
Electric
heating coil
1 stage
BE1
2 stages
BE2
3 stages
BE3
2-way mixing box with
face and top dampers
MD1
2-way mixing box with top
and bottom dampers
MD2
In line 3-way mixing box
with top dampers
MD3
Superposed 3-way mixing
box with top dampers
MD3
Fan 3-speed switch
CMVM
Remote control including
summer/winter change-
over, room thermostat,
on/off, and fan 3-speed
switch. Valve and fan
cycling action.
TRM-FA
Remote control including
summer/winter change-
over, room thermostat,
on/off, and fan 3-speed
switch. Valve cycling only
action.
TRM-VP
Double skin casing panel
DP
RAL 9010 painting
PT
Moisture eliminator
EL
Air-to-air heat recuperator
RP
12 mm metallic filter with G1
efficiency replacing standard
filter
FM1
External
filter
section
12 mm metallic,
G1 efficiency
FA1
12 mm synthetic,
G2 efficiency
FA2
50 mm synthetic,
G4 efficiency
FA4
Parallel blade shut-off damper
AG
Two-way discharge air plenum
PLE
90° discharge air plenum
R
Inlet duct collar
CA
Flexible connection for inlet side,
outlet side or mixing boxes
M
Silencer
PAS
Weather hood
AP
Roof
TO
