Page 8
Mounting Possibilities (continued)
SINGLE SECTION UNITS (VERTICAL)
Arrangement VP6 Arrangement VP7 Arrangement VP1
DOUBLE SECTION UNITS (VERTICAL)
Arrangement VM69A Arrangement VM80 Arrangement VM90E Arrangement VM79A
A
B
D
E
A
B
Arrangement VM59A Arrangement VM49A Arrangement VM39B Arrangement VM19B
A
C
B
A
C
B
B
C
A
B
A
See page 20 for overall dimensions and page 26 for weights.
