Page 24
Dimensions of Options (in mm)
External filter : FA1 - FA2 - FA4
320
370
85
A
B
90
2525
90
30 30
25
740
370
740
185185
C
40
PVC Ø30/32 condensate drain connection on service side
320 2525
30
A
B
90
90
370
50
130
D
324
50
±15
370
200
E
B
323
110
F
200
380
20
20
57
Sizes A B C D E F
1.39 582 762 710 586 390 587
2.69 970 1150 1098 974 790 975
3.99 1320 1500 1448 1324 1190 1325
Dimensions in mm.
All flexible connectors are supplied loose
Sizes 1.39 2.69 3.99
Left or right
side
750 580 780
Top or bottom
side
350 350 350
Minimum space
for filter access
1.39 2.69 3.99
630 550 740
Filter access
(service side)
Plate heat exchanger for heat recovery : RP
Inlet duct collar : CA Flexible connectors : M
Discharge plenum : PLE Discharge plenum : R
