Airwell Wespak 2.69 [6/28] Mounting possibilities
![Airwell Wespak 2.69 [6/28] Mounting possibilities](/views2/1408181/page6/bg6.png)
Page 6
Mounting Possibilities
FAN SECTION
Arrangement HM8 Arrangement HM9A Arrangement HM9D
B
A
E
D
Arrangement VM8 Arrangement VM9A Arrangement VM9D
A B
E D
See page 20 for overall dimensions and page 26 for weights.
See page 20 for overall dimensions and page 26 for weights.
SINGLE SECTION UNITS (HORIZONTAL)
Arrangement HP0 Arrangement HP1 Arrangement HP2
Arrangement HP3 Arrangement HP4 Arrangement HP5
Arrangement HP6 Arrangement HP7
