PRESSOSTATS SETTINGS
LP : Low Pressure fixed setting: 1.5 bar (20 PSI) reset at 35 PSI
HP : High Pressure fixed setting: 29 bar (420 PSI) reset at 305 PSI
COLOUR CODE
BK : Black OG : Orange GNYE : Green/Yellow
BN : Brown WH : White RD : Red
BU : Blue GY : Grey VT : Violet
YE : Yellow
VENTILATION
MV : Treated air fan motor.
K3 : MV contactor.
FT3 : MV thermal relay.
WATER CIRCUIT
Y1 : Water circuit valve (not supplied-available in option).
FDP : Water circuit inlet / outlet differential pressostat
CONTROL AND REGULATION
RCL : Local control module.
ICT : Anti-freezing protection sensors.
RT : Air temperature sensor.
LWT : Outlet water temperature sensor.
SM : Remote ON/OFF switch, 100 m maximum (Not supplied -Please consult us for longer distances).
CLK : CLOCK input remote ON/OFF
REMOTE MANAGEMENT AND PROGRAMMING MODULE KIT (<100M)
µBMS : Supervision module
FAULT REPORTING OPTION
KA2 : Remote fault reporting relay (8 A max / 230 V)
ELECTRIC HEATING BATTERY OPTION
FF2 : Fuse carrier for heating
EC : Heating elements
K2 : Power contactor for heating elements
FA : Automatic reset safety thermostats.
FM : Manual reset safety thermostats.
