Airwell HRW 096 [8/42] Technical specifications
![Airwell HRW 096 [8/42] Technical specifications](/views2/1409405/page8/bg8.png)
6
ÉLECTRIC SPÉCIFICATIONS
TECHNICAL SPECIFICATIONS
OPERATING LIMITS
ENVIRONMENT
This equipment is designed EXCLUSIVELY for INDOOR installation.
In general, sheltered locations such as garages, roof space, etc, do not provide sufficient protection against extreme
temperatures and/or humidity and may be harmful to the unit’s performance, reliability and service life.
AIR TEMPERATURE LIMITS
WATER TEMPERATURE LIMITS
db: dry bulb wb: wet bulb
(1) At nominal air and water flow conditions in accordance with the standard: EN 14511-2
(2) The minimum and maximum values cannot be added together. If one of the values is at its maximum or minimum
level, the other two values must not exceed the normal operating conditions specified for a standard unit.
*Please consult us for operating conditions exceeding these temperatures.
Initial start-up and winter operation of the units are guaranteed down to an ambient temperature of 5 °C, with
the return air intake temperature at 5 °C and the water inlet temperature at 13 °C, with the nominal air and water
flows used for the performance test in accordance with the standard: EN 14511-2.
Note: These operating operation are neither normal nor intended for continuous operation. It is
understood that the unit is only subjected such conditions at start-up for bringing the temperature
of the air-conditioned area to the right temperature.
ELECTRICAL POWER SUPPLY
A variance of ±10% is acceptable in relation to the operating voltage marked on the appliance’s Maker’s Plate.
Phase imbalance on three phase units must not exceed 2%.
Operating voltages:
400V / 3 ph / 50 Hz + N (360 Volts minimum; 440 Volts maximum.)
Comments: the stated voltages represent the accepted range. However, certain components may be subject
to premature wear on appliances operating continuously, for extensive periods, on abnormally low or high
voltages.
Standard unit
Cooling Heating
Minimum ambient temperature 10 °C 10 °C
Normal ambient temperature 27 °C 20 °C
Maximum ambient temperature 38 °C 30 °C
Minimum air intake temperature (1) (2) 10 °C 10 °C
Normal air intake temperature db/wb 27/19 °C 20 °C
Maximum air intake temperature bs/bh (1) (2) 38/28 °C 27 °C
Standard unit
Cooling Heating
Minimum water inlet temperature (1)(2) 15 °C * 13 °C
Normal water inlet temperature 30 °C 20 °C
Maximum water inlet temperature (1)(2) 50 °C * 32 °C
