MAINTENANCE AND SERVICING

1. Normal maintenance of the appliances is generally limited to replacing filters.

2. The filters must be changed at regular intervals. The frequency is dependent on the specific application

conditions. Certain installations, for example in hotels where there large amounts of fluff due to the

frequent bedding changes and the presence of fitted carpets, require more frequent filter changes. It

is recommended that the filters are checked every 60 days during the first year of operation in order

to determine the frequency required. If it is not possible to see light through the filter when it is held

up to the sun or in front of a strong light, the filter must be replaced. A more rigorous standard of

cleanliness may be required.

3. The condensates tray must be checked annually and cleaned and rinsed if necessary.

4. On commissioning, a record of voltages, current draw and temperature variances should be made.

Thereafter, on an annual basis further measurements can be compared to these initial values and

will be useful for giving an overall indication for the equipment’s general condition.

5. The activation of the unit’s safety protection devices is usually caused by air or water problems. These

forced stoppages are a normal protection measure. Ensure that there is no dirt or debris in the air

or water circuits. Check the water and air temperatures and flows (clogged filters).

WARNING

BEFORE COMMENCING ANY WORK ON THE APPLIANCE,

YOU MUST ENSURE THAT THE MAINS POWER SUPPLY IS OFF

AND THAT THERE IS NO POSSIBILITY OF IT BEING ACCIDENTALLY TURNED BACK ON.

FAULT FINDING

NEITHER THE FAN NOR THE COMPRESSOR OPERATE

1. The system is in alarm mode when the mains power supply is switched on. Check the points mentioned

in the "Alarm codes" chart for diagnosis.

2. Check the wiring of the remote control.

3. Check that the appliance is properly set in COOL, HEAT or FAN mode.

4. Check the condition of the fuse or the mains power supply. Check the compressor and fan wiring.

5. Check for any loose or broken wiring and tighten or replace as required.

6. The mains supply voltage is too low. If this is the case, check the supply conditions with the electricity

provider.

FAN DRIVE SYSTEM

Fan shaft and motor bearings are of permanently lubricated, sealed type and require no regular maintenance

other than a check on their general condition. The fan belt tension should be checked regularly and belt surfaces

inspected for cracks or excessive wear.

10 mm maxi.

5 kg

90�

For a quick check, make sure that the small

rope touch each end of the pulleys as shown

on drawing opposite.

Belt alignment Belt tensioning
