17
ELECTRICAL CONNECTIONS
GENERALITIES
Ensure that the available electrical power supply and the network frequency are matched to the required operating
current, taking account of the appliance’s specific location and the current required to supply any other appliances
connected to the same circuit.
1. Ensure that the unit is supplied with the specified voltage. Two stuffing boxes and one grommet hole
are provided on the side of the appliance. They are used respectively for the power and the control
wiring. The power supply line must be properly dimensioned with a motor supply type fuse or a mains
circuit breaker to protect the circuit against voltage surges. (Refer to the Maker’s Plate for the voltages
to be taken into consideration).
2. The electrical power supply three-phase 380V/3ph/50Hz must comprise a neutral to feed the control
circuit.
3. Always shut down the power supply to the unit before connecting the thermostat wiring.
VERY IMPORTANT:
3N~400V-50HZ
The outdoor unit is equipped as standard with a phase sequence and cut-out controller located in the electrical
box.
THIS PRODUCT IS EQUIPPED WITH A PHASE SEQUENCE CONTROLLER. THE LED’s INDICATE THE
FOLLOWING CONDITIONS:
Green LED = 1
Yellow LED =1
Low voltage supply
The compressor rotation
direction is correct
Green LED = 1
Yellow LED =0
Phase inversion or phase
absent (L1)
The compressor and the fans
do not start.
Green LED = 0
Yellow LED =0
Phase absent (L2 or L3)
the compressor and the fans
do not start.
SETTING OF THERMAL PROTECTION AND FUSES
MODELS thermal relay
FT3
Magneto-thermal trip
switch
FF7
FF2 Fuse
/gG type
400V
096 2.6 A 2 A 25 A gG
120 3.4 A 2 A 32 A gG
