RETURN AIR TEMPERATURE MEASUREMENT
As the default factory setting, the jumpers are configured so that return air temperature measurement is performed
via a sensor located on the RCL control module.
If the RCL control module is not sited in the air-conditioned premises or is sited at a distance for various reasons,
we recommend the use of the Return sensor (RT) located on the appliance itself. To activate the Return sensor
(RT) located on the appliance, you just have to cut off the jumper J5 located on the configuration Plug (Refer to
previous paragraph).
If the appliance is installed with an air intake duct and the fan is OFF when there is no demand for
Heating (Jumper J8 Closed) (Refer to previous paragraph), we do NOT recommend the use of the
return air sensor (RT) located on the appliance. It is preferable to install an RCL control module or
an ambient sensor box, available as options from our sales department.
POWER FAILURE
In the event of mains power supply being cut, and after power has been restored, the appliance will restart in the
same mode and with the same settings as before the power cut.
During a power cut, the RCL control module display will be maintained for a maximum period of 10 minutes.
If the power cut lasts longer than 10 minutes, the RCL control module values will be lost, but the appliance will
restart with the same operating parameters as before the power cut. After a power cut lasting more than 10 minutes,
and after restarting, the RCL values will be false.
To minimise disruptions caused by power cuts the µBMS supervision module is equipped with rechargeable batteries
offering 24 hours autonomy. After 24 hours, the time and date will need to be reprogrammed. However, the ON/
OFF programmes and the various zone parameters will remain stored in its memory.
The battery recharging cycle lasts longer than 24 hours. If another power cut occurs whilst the batteries are not
100% charged, the 24 hours autonomy cannot be guaranteed.
Theoretically, there is no need to replace the batteries. However, if they are to be replaced, we recommend using
the same type of batteries as those originally fitted. The old batteries should be disposed of in a recyclable container
intended for this purpose.
REMOTE ON/OFF MAKE/BREAK SWITCH
An make/break switch can be connected to the CLOCK input on the STORM PCB for Remote control of the ON/
OFF modes.
J3 Closed = ON / OFF with restarting via the RCL possible (CLOSED factory setting)
Open = Remote ON /OFF closed = OFF Mode
Operating principle dependent on J3 statuses and CLOCK input
J3=>open
If CLOCK = Closed, then OFF Mode and no command possible via the RCL. In this event, CLOCK input
has priority.
If CLOCK = Open, then ON Mode.
Switching CLOCK input from the Closed position to the Open position results in ON Mode, irrespective of the
Mode prior to switching.
J3=>Closed
This configuration provides the same level of priority between the CLOCK input and the RCL:
If CLOCK = Closed => then ON Mode
If CLOCK = Open => then OFF Mode
Switching CLOCK input from the Open position to the Closed position results in ON Mode, irrespective of the
Mode prior to switching.
General remarks:
A separate make/break switch must be used for each machine.
We recommend the use of wire with a maximum section of 1 mm².
