D-Link DIR-826L [5/142] Package contents

1D-Link DIR-826L User Manual

Section 1 - Product Overview

Product Overview

Package Contents

Note: Using a power supply with a dierent voltage rating than the one included with the DIR-826L will cause damage and void the warranty

for this product.

If any of the above items are missing, please contact your reseller.

DIR-826L Wireless N600 Dual Band Gigabit Cloud Router

Ethernet Cable

Power Adapter

WI-FI Conguration Note

Wi-Fi Conguration Note
