English
6
* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link Orange 100Mbps/1Gbps
connection
Blinking Data Activity
On Link Green 2.5Gbps connection
** If you use a 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”. See the table below
for connection details in accordance with the type of speaker you use.
Audio Output
Channels
Front Speaker
(No. 7)
Rear Speaker
(No. 5)
Central / Bass
(No. 4)
Line In
(No. 6)
2 V -- -- --
4 V V -- --
6 V V V --
8 V V V V
ACT/LINK LED
SPEED LED
LAN Port
Chapter 1 Introduction
ank you for purchasing ASRock Z390 Phantom Gaming SLI/ac / Z390 Phantom
Gaming SLI motherboard, a reliable motherboard produced under ASRock’s
consistently stringent quality control. It delivers excellent performance with robust
design conforming to ASRock’s commitment to quality and endurance.
1.1 Package Contents
•
ASRock Z390 Phantom Gaming SLI/ac / Z390 Phantom Gaming SLI Motherboard
(ATX Form Factor)
•
ASRock Z390 Phantom Gaming SLI/ac / Z390 Phantom Gaming SLI Quick Installation
Guide
•
ASRock Z390 Phantom Gaming SLI/ac / Z390 Phantom Gaming SLI Support CD
•
1 x I/O Panel Shield
•
2 x Serial ATA (SATA) Data Cables (Optional)
•
1 x ASRock SLI_HB_Bridge_2S Card (Optional)
•
2 x Screws for M.2 Sockets (Optional)
•
2 x ASRock WiFi 2.4/5 GHz Antennas (Optional) (for Z390 Phantom Gaming SLI/ac
only)
