91
Select your desired port for VLAN Mapping function. All the ports are disabled for VLAN
Mapping function by default.
Configuration Procedure of VLAN VPN Function:
Step
Operation
Description
1
Enable VPN mode. Required. On the VLAN→VLAN VPN→VPN Config page,
enable the VPN mode.
2
Configure the global TPID. Optional. On the VLAN→VLAN VPN→VPN Config page,
configure the global TPID basing on the devices
connected to the up-link port.
3
Set the VPN up-link port. Required. On the VLAN→VLAN VPN→VPN Config page,
specify the desired port to be the VPN up-link port. It’s
required to set the port connected to the backbone
networks to be up-link port.
4
Create VLAN Mapping
entries.
Required. On the VLAN→VLAN VPN→VL
AN Mapping
page, configure the VLAN Mapping entries basing on the
actual application.
5
Create SP (Service
Provider) VLAN.
Optional. On the VLAN→802.1Q VLAN page, create the
SP VLAN. For the steps of creating VLAN, please refer to
802.1Q VLAN.
Configuration Procedure of VLAN Mapping Function:
Step
Operation
Description
1
Create VLAN Mapping
entries.
Required. On the VLAN→VLAN VPN→
VLAN Mapping
page, configure the VLAN Mapping entries basing on the
actual application.
2
Enab
le VLAN Mapping
function for port.
Required. On the VLAN→VLAN VPN→Port Enable page,
enable VLAN Mapping function for the ports.
3
Create SP (Service
Provider) VLAN
Optional. On the VLAN→802.1Q VLAN page, create the
SP VLAN. For the steps of creating VLAN, please refer to
802.1Q VLAN.
6.8 Private VLAN
Private VLANs, designed to save VLAN resources of uplink devices and decrease broadcast,
are sets of VLAN pairs that share a common primary identifier. To guarantee user information
security, the ease with which to manage and account traffic for service providers, in campus
network, service providers usually require that each individual user is layer-2 separated. VLAN
feature can solve this problem. However, as stipulated by IEEE 802.1Q protocol, a device can
only support up to 4094 VLANs. If a service provider assigns one VLAN per user, the VLANs will
be far from enough; as a result, the number of users this service provider can support is limited.
