Package Contents
The following items should be found in your box:
One T2500-28TC switch
One power cord
One console cable
Two mounting brackets and other fittings
Installation Guide
Resource CD for T2500-28TC switch, including:
• This User Guide
• The CLI Reference Guide
• SNMP Mibs
• 802.1X Client Software
• Other Helpful Information
Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact your distributor.
